12.7.19

তিন ‘ই’ তে স্বপ্নের ক্যারিয়ার | (EEE)









ক্যারিয়ার নিয়ে সবারই কমবেশি ভাবনা থাকে। কিছু কিছু বিষয় আছে যা নিয়ে লেখাপড়া করলে চাকরি পাওয়া কিংবা স্বপ্নের ক্যারিয়ার নিয়ে একটু কমই চিন্তা করতে হয়। এমন একটি বিষয় হচ্ছে ইলেকট্রিক্যাল অ্যান্ড ইলেকট্রনিক ইঞ্জিনিয়ারিং। সংক্ষেপে যাকে বলে ইইই। বিজ্ঞানের শিক্ষার্থীদের মধ্যে বিষয়টি বেশ আগ্রহ জন্মিয়েছে। এর কারণও আছে। বিদেশ তো বটেই দেশেও ইইই গ্রাজুয়েটদের জন্য প্রচুর কর্মক্ষেত্র তৈরি হয়েছে। পাস করার পর কাংক্ষিত চাকরি পেতে অপেক্ষা করতে হয় না। ইইই ইঞ্জিনিয়াররা বিদেশেও উচ্চতর শিক্ষালাভ কিংবা গবেষণায় ভালো সুযোগ পাচ্ছেন। উত্তর আমেরিকা এবং ইউরোপের দেশগুলোর নামকরা বিশ্ববিদ্যালয়ে স্কলারশিপ নিয়ে পড়তে যাচ্ছেন বাংলাদেশসহ এশিয়ার বহু শিক্ষার্থী।

প্রসপেক্ট
গতানুগতিক বিষয়ে পড়ালেখা করে চাকরি পাওয়া কঠিন। কিন্তু ইইই গ্রাজুয়েটদের ক্ষেত্রে বিষয়টি ভিন্ন। বাংলাদেশে বিভিন্ন টেলিকম কোম্পানি, ইলেকট্রনিক কোম্পানি, বিভিন্ন শিল্প কারখানাসহ অনেক জায়গাতেই এই বিষয়ের ইঞ্জিনিয়ারদের চাহিদা রয়েছে। দেশের উদীয়মান অ্যানার্জি ও পাওয়ার সেক্টরে ইইই প্রকৌশলীদের ব্যাপক চাহিদা সৃষ্টি হচ্ছে। বুয়েট থেকে ইইই পাস করা একটি বেসরকারি পাওয়ার কোম্পানির কর্মকর্তা আনোয়ারুল আজিম বলেন, ক্যারিয়ারের শুরুতে আমি স্পষ্ট ভবিষ্যৎ দেখতে পাচ্ছি। এই বিষয়ে যেই পড়তে চান, আমি অবশ্যই তাকে স্বাগত জানাব। দেশে এবং বিদেশে, সব জায়গাতেই এই বিষয়ে পড়াশোনা করার যেমন সুযোগ রয়েছে, তেমনি চাকরির জন্য জায়গাও রয়েছে অনেক। আজহারুল ইসলাম সম্প্রতি বেসরকারি বিশ্ববিদ্যালয় থেকে ইইই পাস করেছেন। তিনি বিটিআরসির অ্যাসিসটেন্ট ইঞ্জিনিয়ার পদে যোগ দিয়েছেন। প্রসপেক্ট সম্পর্কে বলেন, ইইই প্রকৌশল নিঃসন্দেহে একটি সম্মানজনক পেশা। বাংলাদেশে এই ধরনের পেশার মূল্যায়ন অনেকটাই দৃশ্যমান। আমার মনে হয় আমি সঠিক বিষয় নিয়েই পড়ালেখা করেছি।

সামনে সুদিন

কিছুদিন আগে নাজমুল হাসান জুয়েল ইইই পাস করে ডিপিডিসিতে সহকারী প্রকৌশলী হিসেবে যোগ দিয়েছেন। নিজের অবস্থান থেকে পর্যবেক্ষণ করে এই পেশা প্রসঙ্গে তিনি বলেন, বাংলাদেশে প্রতি বছর যে পরিমাণ ইলেকট্রিক্যাল ইঞ্জিনিয়ার তৈরি হয়, তার চেয়ে বহু গুণ চাকরির ক্ষেত্র তৈরি হচ্ছে। অন্য সব ইঞ্জিনিয়ারদের তুলনায় দেশে ও বিদেশে ইলেকট্রিক্যাল ইঞ্জিনিয়ারদের চাহিদা বেশি। চাহিদা থাকায় দ্রুত প্রতিষ্ঠান পরিবর্তনও করা যায়। তিনি বলেন, আমরা ৩৮ জন ডিপিডিসিতে যোগ দিয়েছি। তার মধ্যে ৩৪ জনই হচ্ছে ইলেকট্রিক্যাল, ২ জন সিভিল ও ২ জন সিএসই প্রকৌশলী। তাই নিজের ভবিষ্যৎ বাছাইয়ের বেলায় কোনো প্রকার দ্বিধা ছাড়াই এই বিষয়কে বেছে নিতে পারে যে কেউ।

কোথায় পড়বেন

ইইই পড়তে হলে আপনাকে বিজ্ঞান বিভাগ থেকে মাধ্যমিক ও উচ্চ মাধ্যমিক পাস হতে হবে। যারা সদ্য এইচএসসি পাস করেছেন বুয়েট, চুয়েট, রুয়েটসহ দেশের সব সরকারি ইঞ্জিনিয়ারিং বিশ্ববিদ্যালয়ে ভর্তি পরীক্ষা দিয়ে আপনিও এ বিষয়ে পড়ার সুযোগ নিতে পারেন। এছাড়া ঢাকা বিশ্ববিদ্যালয়সহ বেশ কয়েকটি সরকারি বিশ্ববিদ্যালয়েও বিষয়টি পড়ানো হচ্ছে। এসব বিশ্ববিদ্যালয়ে চলতি সেশনে অনলাইনে ভর্তি আবেদন ইতিমধ্যে শুরু হয়ে গেছে। হাতেগোনা দুএকটি বাদে প্রায় সব বেসরকারি বিশ্ববিদ্যালয়েও এ বিষয়টি পড়ানো হচ্ছে।

সাক্ষাৎকারে প্রফেসর ড. মো. রিজওয়ান খান
প্রফেসর ড. মো. রিজওয়ান খান দেশের পাওয়ার ও অ্যানার্জি সেক্টর নিয়ে হাতেগোনা যে কজন ব্যক্তি গবেষণা করছেন তাদের মধ্যে অন্যতম তিনি। বুয়েটের ইলেকট্রিক্যাল অ্যান্ড ইলেকট্রনিক ইঞ্জিনিয়ারিং (ইইই) বিভাগে দীর্ঘ সময় অধ্যাপনা করেছেন। দেশে ইইই শিক্ষার বিস্তারে অনন্য ভূমিকা রাখা এ শিক্ষাবিদ ২০১৭-’১৮ সালের জন্য ইইই ইঞ্জিনিয়ারদের দুনিয়ার সবচেয়ে বড় পেশাদার সংগঠন- ইন্সটিটিউট অব ইলেট্রিক্যাল অ্যান্ড ইলেকট্রনিক ইঞ্জিনিয়ারিংয়ের ডিসটিংগুইসড লেকচারার হিসেবে মনোনিত হয়েছেন। ইইই গ্রাজুয়েটদের প্রসপেক্ট ও জব অপরচ্যুনিটিসহ চাকরি প্রার্থীদের প্রস্তুতির বিষয়ে ড. রিজওয়ানের সঙ্গে কথা হয় যুগান্তরের। সাক্ষাৎকারটি ছাপা হল-

যুগান্তর : ইইই গ্রাজুয়েটদের জব অপরচ্যুনিটি সম্পর্কে জানতে চাই?

ড. রিজওয়ান খান : ইলেকট্রিক্যাল অ্যান্ড ইলেকট্রনিক ইঞ্জিনিয়ারিং (ইইই) একটি ডায়নামিক সাবজেক্ট। বিজ্ঞানের শিক্ষার্থীদের পছন্দ তালিকার শুরুর দিকেই অবস্থান করছে এটি। এর কারণও আছে। দেশে-বিদেশে এ বিষয়ের শিক্ষার্থীদের প্রচুর কর্মসংস্থানের সুযোগ হচ্ছে। দেশে পাওয়ার সেক্টর গ্রো করছে। সেখানে এ বিষয়ের গ্রাজুয়েটদের কাজের যথেষ্ট চাহিদা সৃষ্টি হয়েছে। দেশে ইলেকট্রনিক ইন্ডাস্ট্রি এগিয়ে যাচ্ছে। বর্তমানে ইলেকট্রনিক কোম্পানিগুলো ভালো বেতনে ইইই গ্রাজুয়েটদের নিয়োগ দিচ্ছে। নবায়নযোগ্য অ্যানার্জি সেক্টরসহ বিদ্যুৎ সংশ্লিষ্ট প্রতিষ্ঠানগুলোতে এ বিষয়ের ডিগ্রিধারীদের চাকরি হচ্ছে। আইসি সফটওয়্যার নির্মাণ প্রতিষ্ঠানগুলোতে ইইই ইঞ্জিনিয়ারদের প্রসপেক্ট ভালো। এছাড়া কমিউনিকেশন সেক্টর বিশেষ করে টেলিকম কোম্পানিগুলোতে এ বিষয়ের গ্রাজুয়েটদের চাহিদা রয়েছে। ইলেট্রিক্যাল ইঞ্জিনিয়ারদের আয়ের একটি বড় ক্ষেত্র হয়ে উঠছে আউটসোর্সিং।

পাওয়ার সার্কিটসহ বিভিন্ন পণ্য তৈরি করে ঘরে বসেই ভালো আয় করতে পারবেন আউটসোর্সাররা।

যুগান্তর : সরকারি কোন কোন প্রতিষ্ঠানে চাকরি পাচ্ছে ইইই গ্রাজুয়েটরা?

ড. রিজওয়ান খান : বিটিটিবি, বিটিআরসিসহ টেলিকম সেক্টরে সুযোগ রয়েছে। এসব প্রতিষ্ঠানে শুরুতেই অ্যাসিসটেন্ট ইঞ্জিনিয়ার পদে চাকরিতে নিয়োগ পান তারা। আণবিক শক্তি কমিশন, জাতীয় বিদ্যুৎ বোর্ডসহ রাষ্ট্রায়ত্ব বিভিন্ন পাওয়ার জেনারেটর কোম্পানিতেও চাকরির সুযোগ হচ্ছে। বিসিএসসহ বিভিন্ন সরকারি চাকরির পরীক্ষায় অংশ নিতে পারেন। যারা ট্র্যাক চেঞ্জ করতে চান তারা স্বায়ত্তশাসিত প্রতিষ্ঠান এবং রাষ্ট্রায়ত্ব ও বেসরকারি বিভিন্ন ব্যাংকেও চাকরিতে যোগ দিতে পারেন। মেধাবীরা শিক্ষকতা-গবেষণাও করতে পারে। দেশের ইঞ্জিনিয়ারিং বিশ্ববিদ্যালয়, সরকারি বিশ্ববিদ্যালয়, বেসরকারি বিশ্ববিদ্যালয়গুলোতে ইইই বিষয়ের প্রচুর শিক্ষক দরকার হচ্ছে।

যুগান্তর : টেলিকম কোম্পানিগুলোতে নিয়োগের ক্ষেত্রে আবেদনকারীর কোন যোগ্যতা গুরুত্ব দিয়ে দেখা হয়?

ড. রিজওয়ান খান : টেলিকমিউনিকেশন রিলেটেড বিষয়গুলোতে আবেদনকারীর কতটুকু দখল আছে সেটি গুরুত্ব দিয়ে বিবেচনায় নেয়া হয়। এছাড়া আবেদনকারীর কমিউনিকেশন স্কিল, স্মার্টনেস, আর্ট অব প্রেজেনটেশন এসব বিষয় দেখা হয়।

যুগান্তর : দেশে সরকারি-বেসরকারি মিলিয়ে কয়টি বিশ্ববিদ্যালয়ে ইইই পড়ানো হচ্ছে?

ড. রিজওয়ান খান : বুয়েট, রুয়েট, ডুয়েট, কুয়েট, চুয়েটসহ দেশের প্রতিটি পাবলিক ইঞ্জিনিয়ারিং বিশ্ববিদ্যালয়ে ইইই পড়ানো হচ্ছে। এ বিষয়ে শিক্ষার্থীদের আগ্রহ বিবেচনায় নিয়ে হাতেগোনা কয়েকটি বাদে প্রায় সব বেসরকারি বিশ্ববিদ্যালয়ে বিষয়টি পড়ানো হচ্ছে।

যুগান্তর : ইইই পড়ানোর জন্য যে ল্যাব ফ্যাসিলিটিজ দরকার, দেশের শিক্ষা প্রতিষ্ঠানগুলোতে সেটি আছে বলে আপনি মনে করেন কি?

ড. রিজওয়ান খান : ইইই ছাত্রদের ব্যবহারির শিক্ষা নিশ্চিত করতে যে ধরনের ল্যাব দরকার সেটি খুব একটা এক্সপেনসিভ না। কম খরচেই ল্যাব ডেভেলপ করা যায়। তবে কিছু কিছু সফটওয়্যার রয়েছে বেশ দামি। যেমন আইসি সফটওয়্যার কেডেন্স, দাম ২০ লাখের বেশি। এগুলো অপারেট করতে দক্ষ জনবল দরকার। আমার তো মনে হয় বিশ্ববিদ্যালয়গুলো উচ্চ শিক্ষার বিস্তারে আন্তরিক হলে ছাত্রদের ল্যাব ফ্যাসিলিটিজ নিশ্চিত করা কঠিন কিছু নয়।

যুগান্তর : ইইই শিক্ষাটা এখনও ততটা পরিচিত হয়ে উঠেনি। এটি শিক্ষার্থীদের আগ্রহের জায়গা কতটুকু ধরতে পেরেছে। আপনার মূল্যায়ন...

ড. রিজওয়ান খান : ইইই ডিসিপ্লিন নতুন নয়। প্রায় ১০০ বছরের পুরনো। শুরুতে ইলেকট্রিক্যাল ইঞ্জিনিয়ারিং, ইলেকট্রিক্যাল অ্যান্ড কমিউনিকেশন ইঞ্জিনিয়ারিং এবং পরে ইলেকট্রিক্যাল অ্যান্ড কম্পিউটার সায়েন্স অ্যান্ড ইঞ্জিনিয়ারিং ও ইলেকট্রিক্যাল অ্যান্ড ইলেকট্রনিক ইঞ্জিনিয়ারিং নামে বিষয়টি পড়ানো হচ্ছে। আর শিক্ষার্থীদের ঝোঁকের বিষয়ে আমার মূল্যায়ন হচ্ছে- সামগ্রিকভাবেই বিজ্ঞান শিক্ষার প্রতি বর্তমান প্রজন্মের শিক্ষার্থীদের আগ্রহে ভাটা পড়েছে। সেই তুলনায় বিজনেস স্টাডিসসহ অন্যান্য বিষয়ে শিক্ষার্থীদের ঝোঁক বেড়েছে। এর কারণ হিসেবে আমি বলব, উচ্চ মাধ্যমিক পর্যন্ত সায়েন্সের ছাত্রদের যে শিক্ষাটা দেয়া হচ্ছে সেটি যথাযথ নয়। বড় একটা ফাঁক থেকে যাচ্ছে। বিশেষ করে গণিত ও বিজ্ঞানের বিষয়গুলোতে শিক্ষার্থীদের দুর্বলতা থেকে যাচ্ছে যা বিশ্ববিদ্যালয় পর্যায়ে এসে ধরা পড়ছে। এর ফলে অনেকে বিজ্ঞানের বিষয়গুলোতে ভর্তি হয়েও পরে ড্রপ আউট করে। পাসের হার ও জিপিএ বাড়লেও উচ্চ মাধ্যমিক পর্যন্ত আমাদের শিক্ষার মান কতটা বাড়ছে সেটি নিয়ে প্রশ্ন থেকে যাচ্ছে। তাই এখনই যদি আমরা বিজ্ঞানের ছাত্রদের প্রতি বিশেষ যত্ন না নেই তবে বিজ্ঞান শিক্ষায় আমরা পিছিয়ে পড়ব। এটি হবে আমাদের জন্য উদ্বেগের।

যুগান্তর : ইইই ছাত্রদের বিদেশে উচ্চ শিক্ষার সুযোগ হচ্ছে কতটা?

ড. রিজওয়ান খান : ইলেকট্রিক্যাল অ্যান্ড ইলেকট্রনিক ইঞ্জিনিয়ারিংয়ের প্রচুর ছাত্র বিদেশে উচ্চ শিক্ষার সুযোগ পাচ্ছে। বুয়েট, কুয়েট, চুয়েট, রুয়েটের বহু গ্রাজুয়েট প্রতিবছর বৃত্তি নিয়ে যুক্তরাষ্ট্র-কানাডার বিশ্ববিদ্যালয়ে পড়তে যাচ্ছে। প্রাইভেট বিশ্ববিদ্যালয়ের গ্রাজুয়েটদের মধ্যেও কেউ কেউ সুযোগ পাচ্ছে। যুক্তরাজ্য ও আয়ারল্যান্ড ছাড়া ইউরোপীয় ইউনিয়নের বিশ্ববিদ্যালয়গুলোতে পড়ার খরচ কম। কিন্তু ভাষা শিখতে হবে। সেই সঙ্গে ভিসা জটিলতাও রয়েছে। সেই তুলনায় বিজ্ঞানের ছাত্রদের জন্য আমেরিকান বিশ্ববিদ্যালয়গুলোতে সুযোগ পাওয়া সহজ। যারা সেখানে পড়তে যাচ্ছে তাদের বেশিরভাগই সেখানে চাকরি কিংবা গবেষণায় ঝুঁকে পড়ছে। কারণ ওইসব দেশে একদিকে যেমন চাকরি পাওয়া সহজ তেমনি বেতনও ভালো। এছাড়া প্রতিষ্ঠান পরিবর্তন করার সুযোগ তো আছেই। বিদেশে উচ্চ শিক্ষা নেয়া গ্রাজুয়েটদের দেশে পর্যাপ্ত চাকরির ব্যবস্থা করা গেলে দেশ লাভবান হতো।

যুগান্তর : সম্প্রতি এইচএসসির ফল বেরিয়েছে। কোন বিষয়ে পড়বে, কোথায় চান্স হবে এসব নিয়ে শিক্ষার্থীরা চিন্তিত। তাদের প্রতি আপনার পরামর্শ কি?

ড. রিজওয়ান খান : ইঞ্জিনিয়ারিং বিশ্ববিদ্যালয়, মেডিকেল, বিশ্ববিদ্যালয়ে যে যেখানে পড়তে চায় সেখানে ভর্তির জন্য এখন থেকেই জোর প্রস্তুতি নিতে হবে। আকাক্সক্ষা অনুযায়ী প্রস্তুতি নিলে সফলতা ধরা দেবেই। এ সময় অনেকেই সাবজেক্ট চয়েজে ভুল করে। অভিভাবকদের আগ্রহে বিষয় পছন্দ করে, ভর্তির পরে অনেকে পড়ার বিষয়ে আগ্রহ খুঁজে পায় না। পছন্দের বিষয় নির্বাচন ছাত্রছাত্রীদের ওপর ছেড়ে দেয়া উচিত। বাজারে চাহিদা আছে, সরাসরি কাজের ক্ষেত্র আছে এমন বিষয় বেছে নেয়াই ভালো।

যুগান্তর : চাকরি প্রার্থীদের প্রতি আপনার বিশেষ কোনো পরামর্শ...

ড. রিজওয়ান খান : বাংলাদেশের প্রাইভেট সেক্টরে শতকরা ৯০ জন চাকরি হচ্ছে। প্রাইভেট সেক্টরে ক্যারিয়ার গড়তে হলে ইংরেজিতে ভালো দখল থাকতে হবে। কারণ বহুজাতিক প্রতিষ্ঠানগুলোতে নিয়োগের প্রধান শর্ত হচ্ছে ইংলিশ ও কমিউনিকেশ স্কিল। চাকরি প্রার্থীদের এটা বাড়াতে হবে।


Source: www.jugantor.com

বিশ্ববিদ্যালয়ে ভর্তি সংক্রান্ত যেকোন প্রয়োজনে নির্ধিদায় যোগাযোগ করতে পারেনঃ 01790123914 (Mahbub)


5.7.19

Transfer Function

Transfer Function



The transfer function of a system is defined as the ratio of Laplace transform of output to the Laplace transform of input where all the initial conditions are zero.

TRANSFER FUNCTION
TRANSFER FUNCTION
TRANSFER FUNCTION
TRANSFER FUNCTION
Where,
  1. T(S) = Transfer function of the system.
  2. C(S) = output.
  3. R(S) = Reference output.
  4. G(S) = Gain.

Steps to obtain transfer function -

Step-1 Write the differential equation.
Step-2 Find out Laplace transform of the equation assuming 'zero' as an initial condition.
Step-3 Take the ratio of output to input.
Step-4 Write down the equation of G(S) as follows -

TRANSFER FUNCTION
Here, a and b are constant, and S is a complex variable

Characteristic equation of a transfer function -

Here, the characteristic equation of a linear system can be obtained by equating the denominator to the polynomial of a transfer function is zero. Thus the characteristic equation of the transfer function of Eq.1 will be:
an sn+a(n-1) s(n-1)+.........+a1 s+a0=0

Poles and Zeros of a transfer function -

Consider the equation 1, the numerator and denominator can be factored in m and n terms respectively:

TRANSFER FUNCTION
Where, TRANSFER FUNCTION is known as the gain factor and's' is the complex frequency.

Poles

Poles are the frequencies of the transfer function for which the value of the transfer function becomes zero.

Zeros

Zeros are the frequencies of the transfer function for which the value of the transfer function becomes zero.
We will apply Sridharacharya method to find the roots of poles and zeros -

TRANSFER FUNCTION
If any poles or zeros coincide then such poles and zeros are called multiple poles or multiple zeros.
If the poles and zeros do not coincide then such poles and zeros are called simple poles or simple zeros.

For example-

Find the transfer function of the following function

TRANSFER FUNCTION
The zeros of the function are S = -3 and the poles of the function are S = 0, S = -2, and multiple poles at S = -4 i.e. the pole of order 2 at S = -4.

The two cases that arise when we consider the whole 'S' plane is:

1. If the no. of zeros are less than no. of poles, i.e., Z<P then the value of transfer function becomes zero for S?? and the order of such zeros is P-Z.
2. If the no. of poles are less than no. of zeros P<Z then the value of transfer function becomes infinity for S??, and the order of such poles is Z-P.
The symbols that are used to locate poles and zeros on S-plane are ?X? and ?O.? The pole is represented by ?X? and zero is represented by 'O.' The pole-zero plot of the above example is as follows -

TRANSFER FUNCTION

Example -1

Find the transfer function of the given network.

TRANSFER FUNCTION
Solution:
Step 1

TRANSFER FUNCTION
TRANSFER FUNCTION
Step 2: By taking the Laplace transform of eq (1) and eq (2) and assuming all initial condition to be zero.

TRANSFER FUNCTION
Step 3: Calculation of transfer function

TRANSFER FUNCTION
Eq (5) is the transfer function

Example- 2

Find the transfer function of the following diagram.

TRANSFER FUNCTION

Solution -

Step 1:Apply KCL at node 'a.'

TRANSFER FUNCTION
Now putting all the values in eq (1)

TRANSFER FUNCTION
Taking Laplace transform of equation (2)

TRANSFER FUNCTION


Reference-
Automatic Control system-S. Hasan Saeed

Classification of Control System

The control system may be classified in a number of ways. Some popular classifications are:
  1. Depending on the methods analysis and design, the system can be linear or non-linear.
  2. Depending upon the type of signals, the system can be time-varying, time-invariant continuous data, discrete data, modulated or unmodulated control system etc.
  3. Depending on the type of system component, the system can be electromechanical, biological, hydraulic, thermal or pneumatic control system etc.
  4. Depending upon the primary purpose, the system can be position control, velocity control etc.

Linear and Non-linear system

Linear system: A system is known as linear if and only if it possesses both homogeneity and superposition properties. Superposition implies that an input r1 (t) gives an output c1 (t) and another input r2 (t) gives the output c2 (t). If two inputs are applied together then the output will be the sum of two outputs:
r1(t) + r2(t) = c1(t) + c2(t)
If our input-output relationship is a straight line passing through the origin, then the system obeys the superposition property. The straight line passing through origin means that the output is zero (0) for zero (0) input.
If the input increases for any system K time from r1 (t) to Kr1 (t) then the magnitude of the output is also increased from c1 (t) to Kc1 (t) then this property is known as homogeneity. This property is a necessary condition for a system to be linear.
Non-Linear System: Non-linear system does not satisfy the superposition principle or homogeneity property, or it is the system whose output is not directly proportional to its input. Here, the stability of the non-linear system depends upon the input and initial status of the system.
In a linear system, if the input is sinusoidal and starts increasing, then the output will also increase but the form will remain the same.
However, in a non-linear system, the form may change with changes in the magnitude of the input. It means if the input is sinusoidal then the output is non-sinusoidal, i.e., the non-linear system.

Time-Variant and Invariant Control System

The system whose parameter vary with time is known as a time-varying control system and the system whose parameter does not vary with time is called as a time-invariant control system.

Continuous data and discrete data control system

In a continuous system, all system variables are the function of continuous time variable 't.' At any time't' they are dependent on time thus they are called continuous data control system.
In discrete data control system, if the signal is not continuously varying with time but it is in the form of pulses, the controlled system is called discrete data control system.
It is of two types
  1. Sampled
  2. Digital
If the signal is in the form of pulse data, the system is called a sampled data control system. The sampled form is shown in the below-drawn diagram.

Classification of Control System
If the signal is in the form of digital code, the system is called a digital control system.

Dynamic and Static system

If in any system the input does not change with the time then the output will also not change with time such system is known as a static system. For example, an electric circuit with resistances.
If the output of the system is a function of time even when the input is constant, such system is called Dynamic system like R, L, C circuit because inductance and capacitance are energy storing devices.


Reference-
Automatic Control system-S. Hasan Saeed

Control Systems Introduction

Control Systems Introduction

Control System Tutorial

Control Systems Tutorial

Control Systems Tutorial provides basic and advanced concepts of Control System Library. Our Control System Tutorial is designed for beginners and professionals both.
Our Control System Tutorial includes all topics of Control System Tutorial such as Control System Introduction, Classification, Transfer Function, Signal flow graphs, Mason gain formula, Block diagram, State Space Model, etc.

Control Systems Introduction

A Control System is a system in which the output is controlled by varying the input. The first control system device was James Watt's Flyball governor, which was invented in 1767. The aim of inventing Flyball governor was to keep the speed of the engine constant by regulating the supply of the steam to the engine.
In a control system, the behavior of the system is described by the differential equations. The differential equations can be either ordinary differential equations or the difference equations.

control systems Introduction
There are two types of control system:
  1. Open loop control system.
  2. Closed loop control system.

Open loop control system

An open-loop control system is a system in which the control action is independent of the desired output signal. In this system, the output signal is not compared with the input signal which means there is no feedback signal in this system. The open-loop control system is also known as a non-feedback control system or control system without feedback.

control systems Introduction

Examples

  1. Automatic washing machine- In this system, the operating time is set manually. After the completion of the set time, the machine stops whether the desired cleanness is obtained or not because there is no feedback signal which the machine can sense.
  2. Immersion rod- In this system, the rod heats up the water but how much hot water is required that cannot be sensed by the rod.

Advantages of an open-loop control system

  1. Open loop systems are simple.
  2. These are economical.
  3. Less maintenance is required and is not difficult.

Disadvantages of open loop control system

  1. Open loop systems are inaccurate.
  2. These systems are not reliable.
  3. These are slow.
  4. Optimization is not possible.

Closed loop control system

A closed loop control system is a system in which control action is dependent on the desired output. In this system, the output signal is compared with the reference input signal, and an error signal is produced then this error signal is fed to the controller to reduce the error to obtain the desired output.

control systems Introduction

Examples

  1. Automatic electric iron.
  2. Servo voltage stabilizer.
  3. An air conditioner.

Advantages of closed-loop systems

  1. These systems are more reliable.
  2. Closed-loop systems are faster.
  3. Many variables can be handled simultaneously.
  4. Optimization is possible.

Disadvantages of closed-loop systems

  1. Closed-loop systems are expensive.
  2. Maintenance is difficult.
  3. Installation is difficult for these systems.

Difference between an open-loop system and closed-loop system

S.NoOpen Loop systemClosed Loop system
1These are easier to build.These are difficult to build.
2These systems are not reliable.These systems are reliable.
3These systems are slow.These systems are faster.
4These systems are generally more stable.These systems are less stable.
5Optimization is not possible.Optimization is possible.
6Examples - Hand dryer, washing machine.Servo voltage stabilizer, air conditioner.

Reference-
Automatic Control system-S. Hasan Saeed



24.5.19

৭ম শ্রেনীর গনিত বইয়ের সমাধান pdf download ২য় অংশ



সপ্তম শ্রেণির গনিত বইয়ের ৮ম, ৯ম, ১০ম ও একাদশ (তথ্য ও উপাত্ত,পেজঃ২৬) অধ্যায়ের সম্পুর্ন সমাধান।
Size: 16 mb
Page: 35

গনিত সমাধানের ১ম অংশ পাবেন



20.5.19

৮ম শ্রেণীর গনিত বইয়ের সম্পুর্ণ সমাধান বা গনিত গাইড।

৮ম শ্রেণীর গনিত বইয়ের সম্পুর্ণ সমাধান বা গনিত গাইড।


 এখানে সবচেয়ে সহজ পদ্ধতিতে সবগুলো অংকের সমাধান করে দেওয়া হয়েছে।

যারা ৮ম শ্রেনীতে পড়ো বা জে এস সি পরীক্ষা দেবে তারা এই পিডিএফ হতে সহজ নিয়ম গুলোর মাধ্যমে অংক গুলো খুব সহজে আয়ত্ব করে নিতে পারবে।

যারা টিউশনি করান তাদেরও খুব উপকারে আসবে।
তাছাড়া ৮ম শ্রেণির গনিত বইটি থেকে বিসিএস রিটেন, ব্যাংক পরীক্ষা ও বিভিন্ন চাকুরী পরীক্ষায় অনেক প্রশ্ন কমন আসে।

মেসেঞ্জারে ও মেইলে অনেকদিন যাবত অনেকেই ৮ম শ্রেণীর গনিত বইয়ের সমাধান চাচ্ছেন। কিন্তু ব্যস্ততার কারনে আর পিডিএফ করা হয়ে উঠেনি।

অনেকে Tanvir ভাইর ব্লগ থেকে ডাউনলোড করার চেষ্টা করছেন কিন্তু কিছু জটিলতার কারনে সরাসরি ডাউনলোড করতে পারেননি । সবার কথা ভেবে মুলত আজকে আপনাদের জন্য তানবির ভাইর করা সমাধান বইয়েরর পিডিএফ  আপনাদে সাথে শেয়ার করলাম। এখান থেকে খুব সহজেই পিডিএফটি ডাউনলোড করতে পারবেন।


কম্পিউটারে Rar file ভেংগে বা মোবাইলে zip file থেকে পড়তে পারেন (সাইজঃ ১২ এমবি)

 Page: 328
 Size: ১২ MB


পি ডিএফটি আমি যেখান থেকে সংগ্রহ করেছি। মোবাইলে পড়তে ডাউনলোড করুন এখান থেকে (সাইজঃ ৯০ এমবি)
 Page: 328
 Size: 90 MB





19.3.19

Programming In ANSI c by Balagurusamy Pdf Download


Programming In ANSI C by Balagurusamy Pdf




Download
Download
  1. Preface No programming technique solves all problems. No programming language produces only correct results. No programmer should start each project from scratch. Object-oriented programming is the current cure-all — although it has been around for much more then ten years. At the core, there is little more to it then finally applying the good programming principles which we have been taught for more then twenty years. C++ (Eiffel, Oberon-2, Smalltalk ... take your pick) is the New Language because it is object-oriented — although you need not use it that way if you do not want to (or know how to), and it turns out that you can do just as well with plain ANSI-C. Only object-orientation permits code reuse between pro- jects — although the idea of subroutines is as old as computers and good program- mers always carried their toolkits and libraries with them. This book is not going to praise object-oriented programming or condemn the Old Way. We are simply going to use ANSI-C to discover how object-oriented pro- gramming is done, what its techniques are, why they help us solve bigger prob- lems, and how we harness generality and program to catch mistakes earlier. Along the way we encounter all the jargon — classes, inheritance, instances, linkage, methods, objects, polymorphisms, and more — but we take it out of the realm of magic and see how it translates into the things we have known and done all along. I had fun discovering that ANSI-C is a full-scale object-oriented language. To share this fun you need to be reasonably fluent in ANSI-C to begin with — feeling comfortable with structures, pointers, prototypes, and function pointers is a must. Working through the book you will encounter all the newspeak — according to Orwell and Webster a language ‘‘designed to diminish the range of thought’’ — and I will try to demonstrate how it merely combines all the good programming princi- ples that you always wanted to employ into a coherent approach. As a result, you may well become a more proficient ANSI-C programmer. The first six chapters develop the foundations of object-oriented programming with ANSI-C. We start with a careful information hiding technique for abstract data types, add generic functions based on dynamic linkage and inherit code by judicious lengthening of structures. Finally, we put it all together in a class hierarchy that makes code much easier to maintain. Programming takes discipline. Good programming takes a lot of discipline, a large number of principles, and standard, defensive ways of doing things right. Pro- grammers use tools. Good programmers make tools to dispose of routine tasks once and for all. Object-oriented programming with ANSI-C requires a fair amount of immutable code — names may change but not the structures. Therefore, in chapter seven we build a small preprocessor to create the boilerplate required. It looks like yet another new object-oriented dialect language (yanoodl perhaps?) but it should not be viewed as such — it gets the dull parts out of the way and lets us concentrate on the creative aspects of problem solving with better techniques. ooc
  2. 2.vi___________________________________________________________________________Preface (sorry) is pliable: we have made it, we understand it and can change it, and it writes the ANSI-C code just like we would. The following chapters refine our technology. In chapter eight we add dynamic type checking to catch our mistakes earlier on. In chapter nine we arrange for automatic initialization to prevent another class of bugs. Chapter ten introduces delegates and shows how classes and callback functions cooperate to simplify, for example, the constant chore of producing standard main programs. More chapters are concerned with plugging memory leaks by using class methods, storing and loading structured data with a coherent strategy, and disciplined error recovery through a system of nested exception handlers. Finally, in the last chapter we leave the confines of ANSI-C and implement the obligatory mouse-operated calculator, first for curses and then for the X Window System. This example neatly demonstrates how elegantly we can design and implement using objects and classes, even if we have to cope with the idiosyn- crasies of foreign libraries and class hierarchies. Each chapter has a summary where I try to give the more cursory reader a run- down on the happenings in the chapter and their importance for future work. Most chapters suggest some exercises; however, they are not spelled out formally, because I firmly believe that one should experiment on one’s own. Because we are building the techniques from scratch, I have refrained from making and using a massive class library, even though some examples could have benefited from it. If you want to understand object-oriented programming, it is more important to first master the techniques and consider your options in code design; dependence on somebody else’s library for your developments should come a bit later. An important part of this book is the enclosed source floppy — it has a DOS file system containing a single shell script to create all the sources arranged by chapter. There is a ReadMe file — consult it before you say make. It is also quite instructive to use a program like diff and trace the evolution of the root classes and ooc reports through the later chapters. The techniques described here grew out of my disenchantment with C++ when I needed object-oriented techniques to implement an interactive programming language and realized that I could not forge a portable implementation in C++. I turned to what I knew, ANSI-C, and I was perfectly able to do what I had to. I have shown this to a number of people in courses and workshops and others have used the methods to get their jobs done. It would have stopped there as my footnote to a fad, if Brian Kernighan and my publishers, Hans-Joachim Niclas and John Wait, had not encouraged me to publish the notes (and in due course to reinvent it all once more). My thanks go to them and to all those who helped with and suffered through the evolution of this book. Last not least I thank my family — and no, object-orientation will not replace sliced bread. Hollage, October 1993 Axel-Tobias Schreiner
  3. 3.vii___________________________________________________________________________ Contents Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1 Abstract Data Types — Information Hiding . . . . . . . . . . . 1 1.1 Data Types . . . . . . . . . . . . . . . . . . . . . . 1 1.2 Abstract Data Types . . . . . . . . . . . . . . . . . . 1 1.3 An Example — Set . . . . . . . . . . . . . . . . . . . 2 1.4 Memory Management . . . . . . . . . . . . . . . . . 3 1.5 Object . . . . . . . . . . . . . . . . . . . . . . . 3 1.6 An Application . . . . . . . . . . . . . . . . . . . . 4 1.7 An Implementation — Set . . . . . . . . . . . . . . . . 4 1.8 Another Implementation — Bag . . . . . . . . . . . . . . 7 1.9 Summary . . . . . . . . . . . . . . . . . . . . . . 9 1.10 Exercises . . . . . . . . . . . . . . . . . . . . . . 9 2 Dynamic Linkage — Generic Functions . . . . . . . . . . . . . 11 2.1 Constructors and Destructors . . . . . . . . . . . . . . 11 2.2 Methods, Messages, Classes and Objects . . . . . . . . . 12 2.3 Selectors, Dynamic Linkage, and Polymorphisms . . . . . . . 13 2.4 An Application . . . . . . . . . . . . . . . . . . . . 16 2.5 An Implementation — String . . . . . . . . . . . . . . . 17 2.6 Another Implementation — Atom . . . . . . . . . . . . . 18 2.7 Summary . . . . . . . . . . . . . . . . . . . . . . 20 2.8 Exercises . . . . . . . . . . . . . . . . . . . . . . 20 3 Programming Savvy — Arithmetic Expressions . . . . . . . . . 21 3.1 The Main Loop . . . . . . . . . . . . . . . . . . . . 21 3.2 The Scanner . . . . . . . . . . . . . . . . . . . . . 22 3.3 The Recognizer . . . . . . . . . . . . . . . . . . . . 23 3.4 The Processor . . . . . . . . . . . . . . . . . . . . 23 3.5 Information Hiding . . . . . . . . . . . . . . . . . . . 24 3.6 Dynamic Linkage . . . . . . . . . . . . . . . . . . . 25 3.7 A Postfix Writer . . . . . . . . . . . . . . . . . . . . 26 3.8 Arithmetic . . . . . . . . . . . . . . . . . . . . . . 28 3.9 Infix Output . . . . . . . . . . . . . . . . . . . . . 28 3.10 Summary . . . . . . . . . . . . . . . . . . . . . . 29 4 Inheritance — Code Reuse and Refinement . . . . . . . . . . . 31 4.1 A Superclass — Point . . . . . . . . . . . . . . . . . . 31 4.2 Superclass Implementation — Point . . . . . . . . . . . . 32 4.3 Inheritance — Circle . . . . . . . . . . . . . . . . . . 33 4.4 Linkage and Inheritance . . . . . . . . . . . . . . . . . 35 4.5 Static and Dynamic Linkage . . . . . . . . . . . . . . . 36 4.6 Visibility and Access Functions . . . . . . . . . . . . . . 37 4.7 Subclass Implementation — Circle . . . . . . . . . . . . . 39
  4. 4.viii___________________________________________________________________________Contents 4.8 Summary . . . . . . . . . . . . . . . . . . . . . . 40 4.9 Is It or Has It? — Inheritance vs. Aggregates . . . . . . . . 42 4.10 Multiple Inheritance . . . . . . . . . . . . . . . . . . 42 4.11 Exercises . . . . . . . . . . . . . . . . . . . . . . 43 5 Programming Savvy — Symbol Table . . . . . . . . . . . . . 45 5.1 Scanning Identifiers . . . . . . . . . . . . . . . . . . 45 5.2 Using Variables . . . . . . . . . . . . . . . . . . . . 45 5.3 The Screener — Name . . . . . . . . . . . . . . . . . 47 5.4 Superclass Implementation — Name . . . . . . . . . . . . 48 5.5 Subclass Implementation — Var . . . . . . . . . . . . . . 50 5.6 Assignment . . . . . . . . . . . . . . . . . . . . . 51 5.7 Another Subclass — Constants . . . . . . . . . . . . . . 52 5.8 Mathematical Functions — Math . . . . . . . . . . . . . 52 5.9 Summary . . . . . . . . . . . . . . . . . . . . . . 55 5.10 Exercises . . . . . . . . . . . . . . . . . . . . . . 55 6 Class Hierarchy — Maintainability . . . . . . . . . . . . . . . 57 6.1 Requirements . . . . . . . . . . . . . . . . . . . . . 57 6.2 Metaclasses . . . . . . . . . . . . . . . . . . . . . 58 6.3 Roots — Object and Class . . . . . . . . . . . . . . . . 59 6.4 Subclassing — Any . . . . . . . . . . . . . . . . . . 60 6.5 Implementation — Object . . . . . . . . . . . . . . . . 62 6.6 Implementation — Class . . . . . . . . . . . . . . . . 63 6.7 Initialization . . . . . . . . . . . . . . . . . . . . . 65 6.8 Selectors . . . . . . . . . . . . . . . . . . . . . . 65 6.9 Superclass Selectors . . . . . . . . . . . . . . . . . . 66 6.10 A New Metaclass — PointClass . . . . . . . . . . . . . . 68 6.11 Summary . . . . . . . . . . . . . . . . . . . . . . 70 7 The ooc Preprocessor — Enforcing a Coding Standard . . . . . . 73 7.1 Point Revisited . . . . . . . . . . . . . . . . . . . . 73 7.2 Design . . . . . . . . . . . . . . . . . . . . . . . 78 7.3 Preprocessing . . . . . . . . . . . . . . . . . . . . 79 7.4 Implementation Strategy . . . . . . . . . . . . . . . . 80 7.5 Object Revisited . . . . . . . . . . . . . . . . . . . . 82 7.6 Discussion . . . . . . . . . . . . . . . . . . . . . . 84 7.7 An Example — List, Queue, and Stack . . . . . . . . . . . 85 7.8 Exercises . . . . . . . . . . . . . . . . . . . . . . 89 8 Dynamic Type Checking — Defensive Programming . . . . . . . 91 8.1 Technique . . . . . . . . . . . . . . . . . . . . . . 91 8.2 An Example — list . . . . . . . . . . . . . . . . . . . 92 8.3 Implementation . . . . . . . . . . . . . . . . . . . . 94 8.4 Coding Standard . . . . . . . . . . . . . . . . . . . . 94 8.5 Avoiding Recursion . . . . . . . . . . . . . . . . . . 98 8.6 Summary . . . . . . . . . . . . . . . . . . . . . . 100 8.7 Exercises . . . . . . . . . . . . . . . . . . . . . . 101
  5. 5.ix___________________________________________________________________________Contents 9 Static Construction — Self-Organization . . . . . . . . . . . . 103 9.1 Initialization . . . . . . . . . . . . . . . . . . . . . 103 9.2 Initializer Lists — munch . . . . . . . . . . . . . . . . 104 9.3 Functions for Objects . . . . . . . . . . . . . . . . . . 106 9.4 Implementation . . . . . . . . . . . . . . . . . . . . 107 9.5 Summary . . . . . . . . . . . . . . . . . . . . . . 109 9.6 Exercises . . . . . . . . . . . . . . . . . . . . . . 110 10 Delegates — Callback Functions . . . . . . . . . . . . . . . 111 10.1 Callbacks . . . . . . . . . . . . . . . . . . . . . . 111 10.2 Abstract Base Classes . . . . . . . . . . . . . . . . . 111 10.3 Delegates . . . . . . . . . . . . . . . . . . . . . . 113 10.4 An Application Framework — Filter . . . . . . . . . . . . 114 10.5 The respondsTo Method . . . . . . . . . . . . . . . . 117 10.6 Implementation . . . . . . . . . . . . . . . . . . . . 119 10.7 Another application — sort . . . . . . . . . . . . . . . . 122 10.8 Summary . . . . . . . . . . . . . . . . . . . . . . 123 10.9 Exercises . . . . . . . . . . . . . . . . . . . . . . 124 11 Class Methods — Plugging Memory Leaks . . . . . . . . . . . 125 11.1 An Example . . . . . . . . . . . . . . . . . . . . . 125 11.2 Class Methods . . . . . . . . . . . . . . . . . . . . 127 11.3 Implementing Class Methods . . . . . . . . . . . . . . 128 11.4 Programming Savvy — A Classy Calculator . . . . . . . . . 131 11.5 Summary . . . . . . . . . . . . . . . . . . . . . . 140 11.6 Exercises . . . . . . . . . . . . . . . . . . . . . . 141 12 Persistent Objects — Storing and Loading Data Structures . . . . 143 12.1 An Example . . . . . . . . . . . . . . . . . . . . . 143 12.2 Storing Objects — puto() . . . . . . . . . . . . . . . . 148 12.3 Filling Objects — geto() . . . . . . . . . . . . . . . . . 150 12.4 Loading Objects — retrieve() . . . . . . . . . . . . . . . 151 12.5 Attaching Objects — value Revisited . . . . . . . . . . . . 153 12.6 Summary . . . . . . . . . . . . . . . . . . . . . . 156 12.7 Exercises . . . . . . . . . . . . . . . . . . . . . . 157 13 Exceptions — Disciplined Error Recovery . . . . . . . . . . . . 159 13.1 Strategy . . . . . . . . . . . . . . . . . . . . . . . 159 13.2 Implementation — Exception . . . . . . . . . . . . . . . 161 13.3 Examples . . . . . . . . . . . . . . . . . . . . . . 163 13.4 Summary . . . . . . . . . . . . . . . . . . . . . . 165 13.5 Exercises . . . . . . . . . . . . . . . . . . . . . . 166 14 Forwarding Messages — A GUI Calculator . . . . . . . . . . . 167 14.1 The Idea . . . . . . . . . . . . . . . . . . . . . . . 167 14.2 Implementation . . . . . . . . . . . . . . . . . . . . 168 14.3 Object-Oriented Design by Example . . . . . . . . . . . . 171 14.4 Implementation — Ic . . . . . . . . . . . . . . . . . . 174
  6. 6.x___________________________________________________________________________Contents 14.5 A Character-Based Interface — curses . . . . . . . . . . . 179 14.6 A Graphical Interface — Xt . . . . . . . . . . . . . . . . 182 14.7 Summary . . . . . . . . . . . . . . . . . . . . . . 188 14.8 Exercises . . . . . . . . . . . . . . . . . . . . . . 189 A ANSI-C Programming Hints . . . . . . . . . . . . . . . . . 191 A.1 Names and Scope . . . . . . . . . . . . . . . . . . . 191 A.2 Functions . . . . . . . . . . . . . . . . . . . . . . 191 A.3 Generic Pointers — void * . . . . . . . . . . . . . . . . 192 A.4 const . . . . . . . . . . . . . . . . . . . . . . . . 193 A.5 typedef and const . . . . . . . . . . . . . . . . . . . 194 A.6 Structures . . . . . . . . . . . . . . . . . . . . . . 194 A.7 Pointers to Functions . . . . . . . . . . . . . . . . . . 195 A.8 Preprocessor . . . . . . . . . . . . . . . . . . . . . 196 A.9 Verification — assert.h . . . . . . . . . . . . . . . . . 196 A.10 Global Jumps — setjmp.h . . . . . . . . . . . . . . . . 196 A.11 Variable Argument Lists — stdarg.h . . . . . . . . . . . . 197 A.12 Data Types — stddef.h . . . . . . . . . . . . . . . . . 198 A.13 Memory Management — stdlib.h . . . . . . . . . . . . . 198 A.14 Memory Functions — string.h . . . . . . . . . . . . . . 198 B The ooc Preprocessor — Hints on awk Programming . . . . . . . 199 B.1 Architecture . . . . . . . . . . . . . . . . . . . . . 199 B.2 File Management — io.awk . . . . . . . . . . . . . . . 200 B.3 Recognition — parse.awk . . . . . . . . . . . . . . . . 200 B.4 The Database . . . . . . . . . . . . . . . . . . . . . 201 B.5 Report Generation — report.awk . . . . . . . . . . . . . 202 B.6 Line Numbering . . . . . . . . . . . . . . . . . . . . 203 B.7 The Main Program — main.awk . . . . . . . . . . . . . . 204 B.8 Report Files . . . . . . . . . . . . . . . . . . . . . 204 B.9 The ooc Command . . . . . . . . . . . . . . . . . . . 205 C Manual . . . . . . . . . . . . . . . . . . . . . . . . . . 207 C.1 Commands . . . . . . . . . . . . . . . . . . . . . . 207 C.2 Functions . . . . . . . . . . . . . . . . . . . . . . 214 C.3 Root Classes . . . . . . . . . . . . . . . . . . . . . 214 C.4 GUI Calculator Classes . . . . . . . . . . . . . . . . . 218 Bibliography . . . . . . . . . . . . . . . . . . . . . . . . . 223
  7. 7.1___________________________________________________________________________ 1 Abstract Data Types Information Hiding 1.1 Data Types Data types are an integral part of every programming language. ANSI-C has int, double and char to name just a few. Programmers are rarely content with what’s available and a programming language normally provides facilities to build new data types from those that are predefined. A simple approach is to form aggregates such as arrays, structures, or unions. Pointers, according to C. A. R. Hoare ‘‘a step from which we may never recover,’’ permit us to represent and manipulate data of essentially unlimited complexity. What exactly is a data type? We can take several points of view. A data type is a set of values — char typically has 256 distinct values, int has many more; both are evenly spaced and behave more or less like the natural numbers or integers of mathematics. double once again has many more values, but they certainly do not behave like mathematics’ real numbers. Alternatively, we can define a data type as a set of values plus operations to work with them. Typically, the values are what a computer can represent, and the operations more or less reflect the available hardware instructions. int in ANSI-C does not do too well in this respect: the set of values may vary between machines, and operations like arithmetic right shift may behave differently. More complicated examples do not fare much better. Typically we would define an element of a linear list as a structure typedef struct node { struct node * next; ... information ... } node; and for the operations we specify function headers like node * head (node * elt, const node * tail); This approach, however, is quite sloppy. Good programming principles dictate that we conceal the representation of a data item and declare only the possible manipulations. 1.2 Abstract Data Types We call a data type abstract, if we do not reveal its representation to the user. At a theoretical level this requires us to specify the properties of the data type by mathematical axioms involving the possible operations. For example, we can remove an element from a queue only as often as we have added one previously, and we retrieve the elements in the same order in which they were added.
  8. 8.2___________________________________________________________________________1 Abstract Data Types — Information Hiding Abstract data types offer great flexibility to the programmer. Since the representation is not part of the definition, we are free to choose whatever is easi- est or most efficient to implement. If we manage to distribute the necessary infor- mation correctly, use of the data type and our choice of implementation are totally independent. Abstract data types satisfy the good programming principles of information hid- ing and divide and conquer. Information such as the representation of data items is given only to the one with a need to know: to the implementer and not to the user. With an abstract data type we cleanly separate the programming tasks of imple- mentation and usage: we are well on our way to decompose a large system into smaller modules. 1.3 An Example — Set So how do we implement an abstract data type? As an example we consider a set of elements with the operations add, find, and drop.* They all apply to a set and an element and return the element added to, found in, or removed from a set. find can be used to implement a condition contains which tells us whether an element is already contained in a set. Viewed this way, set is an abstract data type. To declare what we can do with a set, we start a header file Set.h: #ifndef SET_H #define SET_H extern const void * Set; void * add (void * set, const void * element); void * find (const void * set, const void * element); void * drop (void * set, const void * element); int contains (const void * set, const void * element); #endif The preprocessor statements protect the declarations: no matter how many times we include Set.h, the C compiler only sees the declarations once. This technique of protecting header files is so standard, that the GNU C preprocessor recognizes it and does not even access such a file when its protecting symbol is defined. Set.h is complete, but is it useful? We can hardly reveal or assume less: Set will have to somehow represent the fact, that we are working with sets; add() takes an element, adds it to a set, and returns whatever was added or already present in the set; find() looks for an element in a set and returns whatever is present in the set or a null pointer; drop() locates an element, removes it from a set, and returns whatever was removed; contains() converts the result of find() into a truth value. ____________________________________________________________________________________________ * Unfortunately, remove is an ANSI-C library function to remove a file. If we used this name for a set function, we could no longer include stdio.h.
  9. 9.3___________________________________________________________________________1.4 Memory Management The generic pointer void * is used throughout. On the one hand it makes it impossible to discover what a set looks like, but on the other hand it permits us to pass virtually anything to add() and the other functions. Not everything will behave like a set or an element — we are sacrificing type security in the interest of informa- tion hiding. However, we will see in chapter 8 that this approach can be made completely secure. 1.4 Memory Management We may have overlooked something: how does one obtain a set? Set is a pointer, not a type defined by typedef; therefore, we cannot define local or global variables of type Set. Instead, we are only going to use pointers to refer to sets and ele- ments, and we declare source and sink of all data items in new.h: void * new (const void * type, ...); void delete (void * item); Just like Set.h this file is protected by a preprocessor symbol NEW_H. The text only shows the interesting parts of each new file, the source diskette contains the com- plete code of all examples. new() accepts a descriptor like Set and possibly more arguments for initializa- tion and returns a pointer to a new data item with a representation conforming to the descriptor. delete() accepts a pointer originally produced by new() and recycles the associated resources. new() and delete() presumably are a frontend to the ANSI-C functions calloc() and free(). If they are, the descriptor has to indicate at least how much memory is required. 1.5 Object If we want to collect anything interesting in a set, we need another abstract data type Object described by the header file Object.h: extern const void * Object; /* new(Object); */ int differ (const void * a, const void * b); differ() can compare objects: it returns true if they are not equal and false if they are. This description leaves room for the functionality of strcmp(): for some pairs of objects we might choose to return a negative or positive value to specify an or- dering. Real life objects need more functionality to do something useful. For the moment, we restrict ourselves to the bare necessities for membership in a set. If we built a bigger class library, we would see that a set — and in fact everything else — is an object, too. At this point, a lot of functionality results more or less for free.
  10. 10.4___________________________________________________________________________1 Abstract Data Types — Information Hiding 1.6 An Application With the header files, i.e., the definitions of the abstract data types, in place we can write an application main.c: #include <stdio.h> #include "new.h" #include "Object.h" #include "Set.h" int main () { void * s = new(Set); void * a = add(s, new(Object)); void * b = add(s, new(Object)); void * c = new(Object); if (contains(s, a) && contains(s, b)) puts("ok"); if (contains(s, c)) puts("contains?"); if (differ(a, add(s, a))) puts("differ?"); if (contains(s, drop(s, a))) puts("drop?"); delete(drop(s, b)); delete(drop(s, c)); return 0; } We create a set and add two new objects to it. If all is well, we find the objects in the set and we should not find another new object. The program should simply print ok. The call to differ() illustrates a semantic point: a mathematical set can only contain one copy of the object a; an attempt to add it again must return the original object and differ() ought to be false. Similarly, once we remove the object, it should no longer be in the set. Removing an element not in a set will result in a null pointer being passed to delete(). For now, we stick with the semantics of free() and require this to be acceptable. 1.7 An Implementation — Set main.c will compile successfully, but before we can link and execute the program, we must implement the abstract data types and the memory manager. If an object stores no information and if every object belongs to at most one set, we can represent each object and each set as small, unique, positive integer values used as indices into an array heap[]. If an object is a member of a set, its array element con- tains the integer value representing the set. Objects, therefore, point to the set containing them.
  11. 11.5___________________________________________________________________________1.7 An Implementation — ‘‘Set’’ This first solution is so simple that we combine all modules into a single file Set.c. Sets and objects have the same representation, so new() pays no attention to the type description. It only returns an element in heap[] with value zero: #if ! defined MANY || MANY < 1 #define MANY 10 #endif static int heap [MANY]; void * new (const void * type, ...) { int * p; /* & heap[1..] */ for (p = heap + 1; p < heap + MANY; ++ p) if (! * p) break; assert(p < heap + MANY); * p = MANY; return p; } We use zero to mark available elements of heap[]; therefore, we cannot return a reference to heap[0] — if it were a set, its elements would contain the index value zero. Before an object is added to a set, we let it contain the impossible index value MANY so that new() cannot find it again and we still cannot mistake it as a member of any set. new() can run out of memory. This is the first of many errors, that ‘‘cannot happen’’. We will simply use the ANSI-C macro assert() to mark these points. A more realistic implementation should at least print a reasonable error message or use a general function for error handling which the user may overwrite. For our pur- pose of developing a coding technique, however, we prefer to keep the code uncluttered. In chapter 13 we will look at a general technique for handling excep- tions. delete() has to be careful about null pointers. An element of heap[] is recycled by setting it to zero: void delete (void * _item) { int * item = _item; if (item) { assert(item > heap && item < heap + MANY); * item = 0; } } We need a uniform way to deal with generic pointers; therefore, we prefix their names with an underscore and only use them to initialize local variables with the desired types and with the appropriate names. A set is represented in its objects: each element points to the set. If an ele- ment contains MANY, it can be added to the set, otherwise, it should already be in the set because we do not permit an object to belong to more than one set.
  12. 12.6___________________________________________________________________________1 Abstract Data Types — Information Hiding void * add (void * _set, const void * _element) { int * set = _set; const int * element = _element; assert(set > heap && set < heap + MANY); assert(* set == MANY); assert(element > heap && element < heap + MANY); if (* element == MANY) * (int *) element = set — heap; else assert(* element == set — heap); return (void *) element; } assert() takes out a bit of insurance: we would only like to deal with pointers into heap[] and the set should not belong to some other set, i.e., its array element value ought to be MANY. The other functions are just as simple. find() only looks if its element contains the proper index for the set: void * find (const void * _set, const void * _element) { const int * set = _set; const int * element = _element; assert(set > heap && set < heap + MANY); assert(* set == MANY); assert(element > heap && element < heap + MANY); assert(* element); return * element == set — heap ? (void *) element : 0; } contains() converts the result of find() into a truth value: int contains (const void * _set, const void * _element) { return find(_set, _element) != 0; } drop() can rely on find() to check if the element to be dropped actually belongs to the set. If so, we return it to object status by marking it with MANY: void * drop (void * _set, const void * _element) { int * element = find(_set, _element); if (element) * element = MANY; return element; } If we were pickier, we could insist that the element to be dropped not belong to another set. In this case, however, we would replicate most of the code of find() in drop(). Our implementation is quite unconventional. It turns out that we do not need differ() to implement a set. We still need to provide it, because our application uses this function.
  13. 13.7___________________________________________________________________________1.8 Another Implementation — ‘‘Bag’’ int differ (const void * a, const void * b) { return a != b; } Objects differ exactly when the array indices representing them differ, i.e., a simple pointer comparison is sufficient. We are done — for this solution we have not used the descriptors Set and Object but we have to define them to keep our C compiler happy: const void * Set; const void * Object; We did use these pointers in main() to create new sets and objects. 1.8 Another Implementation — Bag Without changing the visible interface in Set.h we can change the implementation. This time we use dynamic memory and represent sets and objects as structures: struct Set { unsigned count; }; struct Object { unsigned count; struct Set * in; }; count keeps track of the number of elements in a set. For an element, count records how many times this element has been added to the set. If we decrement count each time the element is passed to drop() and only remove the element once count is zero, we have a Bag, i.e., a set where elements have a reference count. Since we will use dynamic memory to represent sets and objects, we need to initialize the descriptors Set and Object so that new() can find out how much memory to reserve: static const size_t _Set = sizeof(struct Set); static const size_t _Object = sizeof(struct Object); const void * Set = & _Set; const void * Object = & _Object; new() is now much simpler: void * new (const void * type, ...) { const size_t size = * (const size_t *) type; void * p = calloc(1, size); assert(p); return p; } delete() can pass its argument directly to free() — in ANSI-C a null pointer may be passed to free(). add() has to more or less believe its pointer arguments. It increments the element’s reference counter and the number of elements in the set:
  14. 14.8___________________________________________________________________________1 Abstract Data Types — Information Hiding void * add (void * _set, const void * _element) { struct Set * set = _set; struct Object * element = (void *) _element; assert(set); assert(element); if (! element —> in) element —> in = set; else assert(element —> in == set); ++ element —> count, ++ set —> count; return element; } find() still checks, if the element points to the appropriate set: void * find (const void * _set, const void * _element) { const struct Object * element = _element; assert(_set); assert(element); return element —> in == _set ? (void *) element : 0; } contains() is based on find() and remains unchanged. If drop() finds its element in the set, it decrements the element’s reference count and the number of elements in the set. If the reference count reaches zero, the element is removed from the set: void * drop (void * _set, const void * _element) { struct Set * set = _set; struct Object * element = find(set, _element); if (element) { if (—— element —> count == 0) element —> in = 0; —— set —> count; } return element; } We can now provide a new function count() which returns the number of ele- ments in a set: unsigned count (const void * _set) { const struct Set * set = _set; assert(set); return set —> count; } Of course, it would be simpler to let the application read the component .count directly, but we insist on not revealing the representation of sets. The overhead of a function call is insignificant compared to the danger of an application being able to overwrite a critical value.
  15. 15.9___________________________________________________________________________1.9 Summary Bags behave differently from sets: an element can be added several times; it will only disappear from the set, once it is dropped as many times as it was added. Our application in section 1.6 added the object a twice to the set. After it is dropped from the set once, contains() will still find it in the bag. The test program now has the output ok drop? 1.9 Summary For an abstract data type we completely hide all implementation details, such as the representation of data items, from the application code. The application code can only access a header file where a descriptor pointer represents the data type and where operations on the data type are declared as functions accepting and returning generic pointers. The descriptor pointer is passed to a general function new() to obtain a pointer to a data item, and this pointer is passed to a general function delete() to recycle the associated resources. Normally, each abstract data type is implemented in a single source file. Ideally, it has no access to the representation of other data types. The descriptor pointer normally points at least to a constant size_t value indicating the space requirements of a data item. 1.10 Exercises If an object can belong to several sets simultaneously, we need a different representation for sets. If we continue to represent objects as small unique integer values, and if we put a ceiling on the number of objects available, we can represent a set as a bitmap stored in a long character string, where a bit selected by the object value is set or cleared depending on the presence of the object in the set. A more general and more conventional solution represents a set as a linear list of nodes storing the addresses of objects in the set. This imposes no restriction on objects and permits a set to be implemented without knowing the representation of an object. For debugging it is very helpful to be able to look at individual objects. A rea- sonably general solution are two functions int store (const void * object, FILE * fp); int storev (const void * object, va_list ap); store() writes a description of the object to the file pointer. storev() uses va_arg() to retrieve the file pointer from the argument list pointed to by ap. Both functions return the number of characters written. storev() is practical if we implement the following function for sets: int apply (const void * set, int (* action) (void * object, va_list ap), ...);
  16. 16.10___________________________________________________________________________1 Abstract Data Types — Information Hiding apply() calls action() for each element in set and passes the rest of the argument list. action() must not change set but it may return zero to terminate apply() early. apply() returns true if all elements were processed.
  17. 17.11___________________________________________________________________________ 2 Dynamic Linkage Generic Functions 2.1 Constructors and Destructors Let us implement a simple string data type which we will later include into a set. For a new string we allocate a dynamic buffer to hold the text. When the string is deleted, we will have to reclaim the buffer. new() is responsible for creating an object and delete() must reclaim the resources it owns. new() knows what kind of object it is creating, because it has the description of the object as a first parameter. Based on the parameter, we could use a chain of if statements to handle each creation individually. The draw- back is that new() would explicitly contain code for each data type which we sup- port. delete(), however, has a bigger problem. It, too, must behave differently based on the type of the object being deleted: for a string the text buffer must be freed; for an object as used in chapter 1 only the object itself has to be reclaimed; and a set may have acquired various chunks of memory to store references to its ele- ments. We could give delete() another parameter: either our type descriptor or the function to do the cleaning up, but this approach is clumsy and error-prone. There is a much more general and elegant way: each object must know how to destroy its own resources. Part of each and every object will be a pointer with which we can locate a clean-up function. We call such a function a destructor for the object. Now new() has a problem. It is responsible for creating objects and returning pointers that can be passed to delete(), i.e., new() must install the destructor infor- mation in each object. The obvious approach is to make a pointer to the destructor part of the type descriptor which is passed to new(). So far we need something like the following declarations: struct type { size_t size; /* size of an object */ void (* dtor) (void *); /* destructor */ }; struct String { char * text; /* dynamic string */ const void * destroy; /* locate destructor */ }; struct Set { ... information ... const void * destroy; /* locate destructor */ };
  18. 18.12___________________________________________________________________________2 Dynamic Linkage — Generic Functions It looks like we have another problem: somebody needs to copy the destructor pointer dtor from the type description to destroy in the new object and the copy may have to be placed into a different position in each class of objects. Initialization is part of the job of new() and different types require different work — new() may even require different arguments for different types: new(Set); /* make a set */ new(String, "text"); /* make a string */ For initialization we use another type-specific function which we will call a construc- tor. Since constructor and destructor are type-specific and do not change, we pass both to new() as part of the type description. Note that constructor and destructor are not responsible for acquiring and releasing the memory for an object itself — this is the job of new() and delete(). The constructor is called by new() and is only responsible for initializing the memory area allocated by new(). For a string, this does involve acquiring another piece of memory to store the text, but the space for struct String itself is allocated by new(). This space is later freed by delete(). First, however, delete() calls the des- tructor which essentially reverses the initialization done by the constructor before delete() recycles the memory area allocated by new(). 2.2 Methods, Messages, Classes and Objects delete() must be able to locate the destructor without knowing what type of object it has been given. Therefore, revising the declarations shown in section 2.1, we must insist that the pointer used to locate the destructor must be at the beginning of all objects passed to delete(), no matter what type they have. What should this pointer point to? If all we have is the address of an object, this pointer gives us access to type-specific information for the object, such as its destructor function. It seems likely that we will soon invent other type-specific functions such as a function to display objects, or our comparison function differ(), or a function clone() to create a complete copy of an object. Therefore we will use a pointer to a table of function pointers. Looking closely, we realize that this table must be part of the type description passed to new(), and the obvious solution is to let an object point to the entire type description: struct Class { size_t size; void * (* ctor) (void * self, va_list * app); void * (* dtor) (void * self); void * (* clone) (const void * self); int (* differ) (const void * self, const void * b); }; struct String { const void * class; /* must be first */ char * text; };
  19. 19.13___________________________________________________________________________2.3 Selectors, Dynamic Linkage, and Polymorphisms struct Set { const void * class; /* must be first */ ... }; Each of our objects starts with a pointer to its own type description, and through this type description we can locate type-specific information for the object: .size is the length that new() allocates for the object; .ctor points to the constructor called by new() which receives the allocated area and the rest of the argument list passed to new() originally; .dtor points to the destructor called by delete() which receives the object to be destroyed; .clone points to a copy function which receives the object to be copied; and .differ points to a function which compares its object to something else. Looking down this list, we notice that every function works for the object through which it will be selected. Only the constructor may have to cope with a partially initialized memory area. We call these functions methods for the objects. Calling a method is termed a message and we have marked the receiving object of the message with the parameter name self. Since we are using plain C functions, self need not be the first parameter. Many objects will share the same type descriptor, i.e., they need the same amount of memory and the same methods can be applied to them. We call all objects with the same type descriptor a class; a single object is called an instance of the class. So far a class, an abstract data type, and a set of possible values together with operations, i.e., a data type, are pretty much the same. An object is an instance of a class, i.e., it has a state represented by the memory allocated by new() and the state is manipulated with the methods of its class. Conventionally speaking, an object is a value of a particular data type. 2.3 Selectors, Dynamic Linkage, and Polymorphisms Who does the messaging? The constructor is called by new() for a new memory area which is mostly uninitialized: void * new (const void * _class, ...) { const struct Class * class = _class; void * p = calloc(1, class —> size); assert(p); * (const struct Class **) p = class; if (class —> ctor) { va_list ap; va_start(ap, _class); p = class —> ctor(p, & ap); va_end(ap); } return p; } The existence of the struct Class pointer at the beginning of an object is extremely important. This is why we initialize this pointer already in new():
  20. 20.14___________________________________________________________________________2 Dynamic Linkage — Generic Functions •p object • ........... class size ctor dtor clone differ struct Class The type description class at the right is initialized at compile time. The object is created at run time and the dashed pointers are then inserted. In the assignment * (const struct Class **) p = class; p points to the beginning of the new memory area for the object. We force a conversion of p which treats the beginning of the object as a pointer to a struct Class and set the argument class as the value of this pointer. Next, if a constructor is part of the type description, we call it and return its result as the result of new(), i.e., as the new object. Section 2.6 illustrates that a clever constructor can, therefore, decide on its own memory management. Note that only explicitly visible functions like new() can have a variable parame- ter list. The list is accessed with a va_list variable ap which is initialized using the macro va_start() from stdarg.h. new() can only pass the entire list to the construc- tor; therefore, .ctor is declared with a va_list parameter and not with its own vari- able parameter list. Since we might later want to share the original parameters among several functions, we pass the address of ap to the constructor — when it returns, ap will point to the first argument not consumed by the constructor. delete() assumes that each object, i.e., each non-null pointer, points to a type description. This is used to call the destructor if any exists. Here, self plays the role of p in the previous picture. We force the conversion using a local variable cp and very carefully thread our way from self to its description: void delete (void * self) { const struct Class ** cp = self; if (self && * cp && (* cp) —> dtor) self = (* cp) —> dtor(self); free(self); } The destructor, too, gets a chance to substitute its own pointer to be passed to free() by delete(). If the constructor decides to cheat, the destructor thus has a chance to correct things, see section 2.6. If an object does not want to be deleted, its destructor would return a null pointer. All other methods stored in the type description are called in a similar fashion. In each case we have a single receiving object self and we need to route the method call through its descriptor:
  21. 21.15___________________________________________________________________________2.3 Selectors, Dynamic Linkage, and Polymorphisms int differ (const void * self, const void * b) { const struct Class * const * cp = self; assert(self && * cp && (* cp) —> differ); return (* cp) —> differ(self, b); } The critical part is, of course, the assumption that we can find a type description pointer * self directly underneath the arbitrary pointer self. For the moment at least, we guard against null pointers. We could place a ‘‘magic number’’ at the beginning of each type description, or even compare * self to the addresses or an address range of all known type descriptions, but we will see in chapter 8 that we can do much more serious checking. In any case, differ() illustrates why this technique of calling functions is called dynamic linkage or late binding: while we can call differ() for arbitrary objects as long as they start with an appropriate type description pointer, the function that actually does the work is determined as late as possible — only during execution of the actual call, not before. We will call differ() a selector function. It is an example of a polymorphic func- tion, i.e., a function that can accept arguments of different types and act differently on them based on their types. Once we implement more classes which all contain .differ in their type descriptors, differ() is a generic function which can be applied to any object in these classes. We can view selectors as methods which themselves are not dynamically linked but still behave like polymorphic functions because they let dynamically linked functions do their real work. Polymorphic functions are actually built into many programming languages, e.g., the procedure write() in Pascal handles different argument types differently, and the operator + in C has different effects if it is called for integers, pointers, or float- ing point values. This phenomenon is called overloading: argument types and the operator name together determine what the operator does; the same operator name can be used with different argument types to produce different effects. There is no clear distinction here: because of dynamic linkage, differ() behaves like an overloaded function, and the C compiler can make + act like a polymorphic function — at least for the built-in data types. However, the C compiler can create different return types for different uses of the operator + but the function differ() must always have the same return type independent of the types of its arguments. Methods can be polymorphic without having dynamic linkage. As an example, consider a function sizeOf() which returns the size of any object: size_t sizeOf (const void * self) { const struct Class * const * cp = self; assert(self && * cp); return (* cp) —> size; }
  22. 22.16___________________________________________________________________________2 Dynamic Linkage — Generic Functions All objects carry their descriptor and we can retrieve the size from there. Notice the difference: void * s = new(String, "text"); assert(sizeof s != sizeOf(s)); sizeof is a C operator which is evaluated at compile time and returns the number of bytes its argument requires. sizeOf() is our polymorphic function which at run time returns the number of bytes of the object, to which the argument points. 2.4 An Application While we have not yet implemented strings, we are still ready to write a simple test program. String.h defines the abstract data type: extern const void * String; All our methods are common to all objects; therefore, we add their declarations to the memory management header file new.h introduced in section 1.4: void * clone (const void * self); int differ (const void * self, const void * b); size_t sizeOf (const void * self); The first two prototypes declare selectors. They are derived from the correspond- ing components of struct Class by simply removing one indirection from the declarator. Here is the application: #include "String.h" #include "new.h" int main () { void * a = new(String, "a"), * aa = clone(a); void * b = new(String, "b"); printf("sizeOf(a) == %un", sizeOf(a)); if (differ(a, b)) puts("ok"); if (differ(a, aa)) puts("differ?"); if (a == aa) puts("clone?"); delete(a), delete(aa), delete(b); return 0; } We create two strings and make a copy of one. We show the size of a String object — not the size of the text controlled by the object — and we check that two different texts result in different strings. Finally, we check that a copy is equal but not identical to its original and we delete the strings again. If all is well, the pro- gram will print something like sizeOf(a) == 8 ok
  23. 23.17___________________________________________________________________________2.5 An Implementation — ‘‘String’’ 2.5 An Implementation — String We implement strings by writing the methods which need to be entered into the type description String. Dynamic linkage helps to clearly identify which functions need to be written to implement a new data type. The constructor retrieves the text passed to new() and stores a dynamic copy in the struct String which was allocated by new(): struct String { const void * class; /* must be first */ char * text; }; static void * String_ctor (void * _self, va_list * app) { struct String * self = _self; const char * text = va_arg(* app, const char *); self —> text = malloc(strlen(text) + 1); assert(self —> text); strcpy(self —> text, text); return self; } In the constructor we only need to initialize .text because new() has already set up .class. The destructor frees the dynamic memory controlled by the string. Since delete() can only call the destructor if self is not null, we do not need to check things: static void * String_dtor (void * _self) { struct String * self = _self; free(self —> text), self —> text = 0; return self; } String_clone() makes a copy of a string. Later both, the original and the copy, will be passed to delete() so we must make a new dynamic copy of the string’s text. This can easily be done by calling new(): static void * String_clone (const void * _self) { const struct String * self = _self; return new(String, self —> text); } String_differ() is certainly false if we look at identical string objects and it is true if we compare a string with an entirely different object. If we really compare two distinct strings, we try strcmp(): static int String_differ (const void * _self, const void * _b) { const struct String * self = _self; const struct String * b = _b; if (self == b) return 0;
  24. 24.18___________________________________________________________________________2 Dynamic Linkage — Generic Functions if (! b || b —> class != String) return 1; return strcmp(self —> text, b —> text); } Type descriptors are unique — here we use that fact to find out if our second argu- ment really is a string. All these methods are static because they should only be called through new(), delete(), or the selectors. The methods are made available to the selectors by way of the type descriptor: #include "new.r" static const struct Class _String = { sizeof(struct String), String_ctor, String_dtor, String_clone, String_differ }; const void * String = & _String; String.c includes the public declarations in String.h and new.h. In order to properly initialize the type descriptor, it also includes the private header new.r which con- tains the definition of the representation for struct Class shown in section 2.2. 2.6 Another Implementation — Atom To illustrate what we can do with the constructor and destructor interface we implement atoms. An atom is a unique string object; if two atoms contain the same strings, they are identical. Atoms are very cheap to compare: differ() is true if the two argument pointers differ. Atoms are more expensive to construct and destroy: we maintain a circular list of all atoms and we count the number of times an atom is cloned: struct String { const void * class; /* must be first */ char * text; struct String * next; unsigned count; }; static struct String * ring; /* of all strings */ static void * String_clone (const void * _self) { struct String * self = (void *) _self; ++ self —> count; return self; } Our circular list of all atoms is marked in ring, extends through the .next com- ponent, and is maintained by the string constructor and destructor. Before the con- structor saves a text it first looks through the list to see if the same text is already stored. The following code is inserted at the beginning of String_ctor():
  25. 25.19___________________________________________________________________________2.6 Another Implementation — ‘‘Atom’’ if (ring) { struct String * p = ring; do if (strcmp(p —> text, text) == 0) { ++ p —> count; free(self); return p; } while ((p = p —> next) != ring); } else ring = self; self —> next = ring —> next, ring —> next = self; self —> count = 1; If we find a suitable atom, we increment its reference count, free the new string object self and return the atom p instead. Otherwise we insert the new string object into the circular list and set its reference count to 1. The destructor prevents deletion of an atom unless its reference count is decre- mented to zero. The following code is inserted at the beginning of String_dtor(): if (—— self —> count > 0) return 0; assert(ring); if (ring == self) ring = self —> next; if (ring == self) ring = 0; else { struct String * p = ring; while (p —> next != self) { p = p —> next; assert(p != ring); } p —> next = self —> next; } If the decremented reference count is positive, we return a null pointer so that delete() leaves our object alone. Otherwise we clear the circular list marker if our string is the last one or we remove our string from the list. With this implementation our application from section 2.4 notices that a cloned string is identical to the original and it prints sizeOf(a) == 16 ok clone?
  26. 26.20___________________________________________________________________________2 Dynamic Linkage — Generic Functions 2.7 Summary Given a pointer to an object, dynamic linkage lets us find type-specific functions: every object starts with a descriptor which contains pointers to functions applicable to the object. In particular, a descriptor contains a pointer to a constructor which initializes the memory area allocated for the object, and a pointer to a destructor which reclaims resources owned by an object before it is deleted. We call all objects sharing the same descriptor a class. An object is an instance of a class, type-specific functions for an object are called methods, and messages are calls to such functions. We use selector functions to locate and call dynamically linked methods for an object. Through selectors and dynamic linkage the same function name will take dif- ferent actions for different classes. Such a function is called polymorphic. Polymorphic functions are quite useful. They provide a level of conceptual abstraction: differ() will compare any two objects — we need not remember which particular brand of differ() is applicable in a concrete situation. A cheap and very convenient debugging tool is a polymorphic function store() to display any object on a file descriptor. 2.8 Exercises To see polymorphic functions in action we need to implement Object and Set with dynamic linkage. This is difficult for Set because we can no longer record in the set elements to which set they belong. There should be more methods for strings: we need to know the string length, we want to assign a new text value, we should be able to print a string. Things get interesting if we also deal with substrings. Atoms are much more efficient, if we track them with a hash table. Can the value of an atom be changed? String_clone() poses an subtle question: in this function String should be the same value as self −> class. Does it make any difference what we pass to new()?
  27. 27.21___________________________________________________________________________ 3 Programming Savvy Arithmetic Expressions Dynamic linkage is a powerful programming technique in its own right. Rather than writing a few functions, each with a big switch to handle many special cases, we can write many small functions, one for each case, and arrange for the proper function to be called by dynamic linkage. This often simplifies a routine job and it usually results in code that can be extended easily. As an example we will write a small program to read and evaluate arithmetic expressions consisting of floating point numbers, parentheses and the usual opera- tors for addition, subtraction, and so on. Normally we would use the compiler gen- erator tools lex and yacc to build that part of the program which recognizes an arith- metic expression. This book is not about compiler building, however, so just this once we will write this code ourselves. 3.1 The Main Loop The main loop of the program reads a line from standard input, initializes things so that numbers and operators can be extracted and white space is ignored, calls up a function to recognize a correct arithmetic expression and somehow store it, and finally processes whatever was stored. If things go wrong, we simply read the next input line. Here is the main loop: #include <setjmp.h> static enum tokens token; /* current input symbol */ static jmp_buf onError; int main (void) { volatile int errors = 0; char buf [BUFSIZ]; if (setjmp(onError)) ++ errors; while (gets(buf)) if (scan(buf)) { void * e = sum(); if (token) error("trash after sum"); process(e); delete(e); } return errors > 0; }
  28. 28.22___________________________________________________________________________3 Programming Savvy — Arithmetic Expressions void error (const char * fmt, ...) { va_list ap; va_start(ap, fmt); vfprintf(stderr, fmt, ap), putc(’n’, stderr); va_end(ap); longjmp(onError, 1); } The error recovery point is defined with setjmp(). If error() is called somewhere in the program, longjmp() continues execution with another return from setjmp(). In this case, the result is the value passed to longjmp(), the error is counted, and the next input line is read. The exit code of the program reports if any errors were encountered. 3.2 The Scanner In the main loop, once an input line has been read into buf[], it is passed to scan(), which for each call places the next input symbol into the variable token. At the end of a line token is zero: #include <ctype.h> #include <errno.h> #include <stdlib.h> #include "parse.h" /* defines NUMBER */ static double number; /* if NUMBER: numerical value */ static enum tokens scan (const char * buf) /* return token = next input symbol */ { static const char * bp; if (buf) bp = buf; /* new input line */ while (isspace(* bp)) ++ bp; if (isdigit(* bp) || * bp == ’.’) { errno = 0; token = NUMBER, number = strtod(bp, (char **) & bp); if (errno == ERANGE) error("bad value: %s", strerror(errno)); } else token = * bp ? * bp ++ : 0; return token; } We call scan() with the address of an input line or with a null pointer to continue work on the present line. White space is ignored and for a leading digit or decimal point we extract a floating point number with the ANSI-C function strtod(). Any other character is returned as is, and we do not advance past a null byte at the end of the input buffer.
  29. 29.23___________________________________________________________________________3.3 The Recognizer The result of scan() is stored in the global variable token — this simplifies the recognizer. If we have detected a number, we return the unique value NUMBER and we make the actual value available in the global variable number. 3.3 The Recognizer At the top level expressions are recognized by the function sum() which internally calls on scan() and returns a representation that can be manipulated by process() and reclaimed by delete(). If we do not use yacc we recognize expressions by the method of recursive descent where grammatical rules are translated into equivalent C functions. For example: a sum is a product, followed by zero or more groups, each consisting of an addition operator and another product. A grammatical rule like sum : product { +|— product }... is translated into a C function like void sum (void) { product(); for (;;) { switch (token) { case ’+’: case ’—’: scan(0), product(); continue; } return; } } There is a C function for each grammatical rule so that rules can call each other. Alternatives are translated into switch or if statements, iterations in the grammar produce loops in C. The only problem is that we must avoid infinite recursion. token always contains the next input symbol. If we recognize it, we must call scan(0) to advance in the input and store a new symbol in token. 3.4 The Processor How do we process an expression? If we only want to perform simple arithmetic on numerical values, we can extend the recognition functions and compute the result as soon as we recognize the operators and the operands: sum() would expect a double result from each call to product(), perform addition or subtraction as soon as possible, and return the result, again as a double function value. If we want to build a system that can handle more complicated expressions we need to store expressions for later processing. In this case, we can not only per- form arithmetic, but we can permit decisions and conditionally evaluate only part of an expression, and we can use stored expressions as user functions within other expressions. All we need is a reasonably general way to represent an expression. The conventional technique is to use a binary tree and store token in each node:
  30. 30.24___________________________________________________________________________3 Programming Savvy — Arithmetic Expressions struct Node { enum tokens token; struct Node * left, * right; }; This is not very flexible, however. We need to introduce a union to create a node in which we can store a numerical value and we waste space in nodes representing unary operators. Additionally, process() and delete() will contain switch state- ments which grow with every new token which we invent. 3.5 Information Hiding Applying what we have learned thus far, we do not reveal the structure of a node at all. Instead, we place some declarations in a header file value.h: const void * Add; ... void * new (const void * type, ...); void process (const void * tree); void delete (void * tree); Now we can code sum() as follows: #include "value.h" static void * sum (void) { void * result = product(); const void * type; for (;;) { switch (token) { case ’+’: type = Add; break; case ’—’: type = Sub; break; default: return result; } scan(0); result = new(type, result, product()); } } product() has the same architecture as sum() and calls on a function factor() to recognize numbers, signs, and a sum enclosed in parentheses: static void * sum (void); static void * factor (void) { void * result; switch (token) { case ’+’: scan(0); return factor();
  31. 31.25___________________________________________________________________________3.6 Dynamic Linkage case ’—’: scan(0); return new(Minus, factor()); default: error("bad factor: ’%c’ 0x%x", token, token); case NUMBER: result = new(Value, number); break; case ’(’: scan(0); result = sum(); if (token != ’)’) error("expecting )"); } scan(0); return result; } Especially in factor() we need to be very careful to maintain the scanner invariant: token must always contain the next input symbol. As soon as token is consumed we need to call scan(0). 3.6 Dynamic Linkage The recognizer is complete. value.h completely hides the evaluator for arith- metic expressions and at the same time specifies what we have to implement. new() takes a description such as Add and suitable arguments such as pointers to the operands of the addition and returns a pointer representing the sum: struct Type { void * (* new) (va_list ap); double (* exec) (const void * tree); void (* delete) (void * tree); }; void * new (const void * type, ...) { va_list ap; void * result; assert(type && ((struct Type *) type) —> new); va_start(ap, type); result = ((struct Type *) type) —> new(ap); * (const struct Type **) result = type; va_end(ap); return result; } We use dynamic linkage and pass the call to a node-specific routine which, in the case of Add, has to create the node and enter the two pointers: struct Bin { const void * type; void * left, * right; };
  32. 32.26___________________________________________________________________________3 Programming Savvy — Arithmetic Expressions static void * mkBin (va_list ap) { struct Bin * node = malloc(sizeof(struct Bin)); assert(node); node —> left = va_arg(ap, void *); node —> right = va_arg(ap, void *); return node; } Note that only mkBin() knows what node it creates. All we require is that the vari- ous nodes start with a pointer for the dynamic linkage. This pointer is entered by new() so that delete() can reach its node-specific function: void delete (void * tree) { assert(tree && * (struct Type **) tree && (* (struct Type **) tree) —> delete); (* (struct Type **) tree) —> delete(tree); } static void freeBin (void * tree) { delete(((struct Bin *) tree) —> left); delete(((struct Bin *) tree) —> right); free(tree); } Dynamic linkage elegantly avoids complicated nodes. .new() creates precisely the right node for each type description: binary operators have two descendants, unary operators have one, and a value node only contains the value. delete() is a very simple function because each node handles its own destruction: binary opera- tors delete two subtrees and free their own node, unary operators delete only one subtree, and a value node will only free itself. Variables or constants can even remain behind — they simply would do nothing in response to delete(). 3.7 A Postfix Writer So far we have not really decided what process() is going to do. If we want to emit a postfix version of the expression, we would add a character string to the struct Type to show the actual operator and process() would arrange for a single output line indented by a tab: void process (const void * tree) { putchar(’t’); exec(tree); putchar(’n’); }
  33. 33.27___________________________________________________________________________3.7 A Postfix Writer exec() handles the dynamic linkage: static void exec (const void * tree) { assert(tree && * (struct Type **) tree && (* (struct Type **) tree) —> exec); (* (struct Type **) tree) —> exec(tree); } and every binary operator is emitted with the following function: static void doBin (const void * tree) { exec(((struct Bin *) tree) —> left); exec(((struct Bin *) tree) —> right); printf(" %s", (* (struct Type **) tree) —> name); } The type descriptions tie everything together: static struct Type _Add = { "+", mkBin, doBin, freeBin }; static struct Type _Sub = { "—", mkBin, doBin, freeBin }; const void * Add = & _Add; const void * Sub = & _Sub; It should be easy to guess how a numerical value is implemented. It is represented as a structure with a double information field: struct Val { const void * type; double value; }; static void * mkVal (va_list ap) { struct Val * node = malloc(sizeof(struct Val)); assert(node); node —> value = va_arg(ap, double); return node; } Processing consists of printing the value: static void doVal (const void * tree) { printf(" %g", ((struct Val *) tree) —> value); } We are done — there is no subtree to delete, so we can use the library function free() directly to delete the value node: static struct Type _Value = { "", mkVal, doVal, free }; const void * Value = & _Value; A unary operator such as Minus is left as an exercise.
  34. 34.28___________________________________________________________________________3 Programming Savvy — Arithmetic Expressions 3.8 Arithmetic If we want to do arithmetic, we let the execute functions return double values to be printed in process(): static double exec (const void * tree) { return (* (struct Type **) tree) —> exec(tree); } void process (const void * tree) { printf("t%gn", exec(tree)); } For each type of node we need one execution function which computes and returns the value for the node. Here are two examples: static double doVal (const void * tree) { return ((struct Val *) tree) —> value; } static double doAdd (const void * tree) { return exec(((struct Bin *) tree) —> left) + exec(((struct Bin *) tree) —> right); } static struct Type _Add = { mkBin, doAdd, freeBin }; static struct Type _Value = { mkVal, doVal, free }; const void * Add = & _Add; const void * Value = & _Value; 3.9 Infix Output Perhaps the highlight of processing arithmetic expressions is to print them with a minimal number of parentheses. This is usually a bit tricky, depending on who is responsible for emitting the parentheses. In addition to the operator name used for postfix output we add two numbers to the struct Type: struct Type { const char * name; /* node’s name */ char rank, rpar; void * (* new) (va_list ap); void (* exec) (const void * tree, int rank, int par); void (* delete) (void * tree); }; .rank is the precedence of the operator, starting with 1 for addition. .rpar is set for operators such as subtraction, which require their right operand to be enclosed in parentheses if it uses an operator of equal precedence. As an example consider
  35. 35.29___________________________________________________________________________3.10 Summary $ infix 1 + (2 — 3) 1 + 2 — 3 1 — (2 — 3) 1 — (2 — 3) This demonstrates that we have the following initialization: static struct Type _Add = {"+", 1, 0, mkBin, doBin, freeBin}; static struct Type _Sub = {"—", 1, 1, mkBin, doBin, freeBin}; The tricky part is for a binary node to decide if it must surround itself with parentheses. A binary node such as an addition is given the precedence of its superior and a flag indicating whether parentheses are needed in the case of equal precedence. doBin() decides if it will use parentheses: static void doBin (const void * tree, int rank, int par) { const struct Type * type = * (struct Type **) tree; par = type —> rank < rank || (par && type —> rank == rank); if (par) putchar(’(’); If our node has less precedence than its superior, or if we are asked to put up parentheses on equal precedence, we print parentheses. In any case, if our description has .rpar set, we require only of our right operand that it put up extra parentheses: exec(((struct Bin *) tree) —> left, type —> rank, 0); printf(" %s ", type —> name); exec(((struct Bin *) tree) —> right, type —> rank, type —> rpar); if (par) putchar(’)’); } The remaining printing routines are significantly simpler to write. 3.10 Summary Three different processors demonstrate the advantages of information hiding. Dynamic linkage has helped to divide a problem into many very simple functions. The resulting program is easily extended — try adding comparisons and an operator like ? : in C.
  36. 36.31___________________________________________________________________________ 4 Inheritance Code Reuse and Refinement 4.1 A Superclass — Point In this chapter we will start a rudimentary drawing program. Here is a quick test for one of the classes we would like to have: #include "Point.h" #include "new.h" int main (int argc, char ** argv) { void * p; while (* ++ argv) { switch (** argv) { case ’p’: p = new(Point, 1, 2); break; default: continue; } draw(p); move(p, 10, 20); draw(p); delete(p); } return 0; } For each command argument starting with the letter p we get a new point which is drawn, moved somewhere, drawn again, and deleted. ANSI-C does not include standard functions for graphics output; however, if we insist on producing a picture we can emit text which Kernighan’s pic [Ker82] can understand: $ points p "." at 1,2 "." at 11,22 The coordinates do not matter for the test — paraphrasing a commercial and OOspeak: ‘‘the point is the message.’’ What can we do with a point? new() will produce a point and the constructor expects initial coordinates as further arguments to new(). As usual, delete() will recycle our point and by convention we will allow for a destructor. draw() arranges for the point to be displayed. Since we expect to work with other graphical objects — hence the switch in the test program — we will provide dynamic linkage for draw().
  37. 37.32___________________________________________________________________________4 Inheritance — Code Reuse and Refinement move() changes the coordinates of a point by the amounts given as arguments. If we implement each graphical object relative to its own reference point, we will be able to move it simply by applying move() to this point. Therefore, we should be able to do without dynamic linkage for move(). 4.2 Superclass Implementation — Point The abstract data type interface in Point.h contains the following: extern const void * Point; /* new(Point, x, y); */ void move (void * point, int dx, int dy); We can recycle the new.? files from chapter 2 except that we remove most methods and add draw() to new.h: void * new (const void * class, ...); void delete (void * item); void draw (const void * self); The type description struct Class in new.r should correspond to the method declarations in new.h: struct Class { size_t size; void * (* ctor) (void * self, va_list * app); void * (* dtor) (void * self); void (* draw) (const void * self); }; The selector draw() is implemented in new.c. It replaces selectors such as differ() introduced in section 2.3 and is coded in the same style: void draw (const void * self) { const struct Class * const * cp = self; assert(self && * cp && (* cp) —> draw); (* cp) —> draw(self); } After these preliminaries we can turn to the real work of writing Point.c, the implementation of points. Once again, object-orientation has helped us to identify precisely what we need to do: we have to decide on a representation and imple- ment a constructor, a destructor, the dynamically linked method draw() and the statically linked method move(), which is just a plain function. If we stick with two-dimensional, Cartesian coordinates, we choose the obvious representation: struct Point { const void * class; int x, y; /* coordinates */ }; The constructor has to initialize the coordinates .x and .y — by now absolutely rou- tine:
  38. 38.33___________________________________________________________________________4.3 Inheritance — ‘‘Circle’’ static void * Point_ctor (void * _self, va_list * app) { struct Point * self = _self; self —> x = va_arg(* app, int); self —> y = va_arg(* app, int); return self; } It turns out that we do not need a destructor because we have no resources to reclaim before delete() does away with struct Point itself. In Point_draw() we print the current coordinates in a way which pic can understand: static void Point_draw (const void * _self) { const struct Point * self = _self; printf(""." at %d,%dn", self —> x, self —> y); } This takes care of all the dynamically linked methods and we can define the type descriptor, where a null pointer represents the non-existing destructor: static const struct Class _Point = { sizeof(struct Point), Point_ctor, 0, Point_draw }; const void * Point = & _Point; move() is not dynamically linked, so we omit static to export it from Point.c and we do not prefix its name with the class name Point: void move (void * _self, int dx, int dy) { struct Point * self = _self; self —> x += dx, self —> y += dy; } This concludes the implementation of points in Point.? together with the support for dynamic linkage in new.?. 4.3 Inheritance — Circle A circle is just a big point: in addition to the center coordinates it needs a radius. Drawing happens a bit differently, but moving only requires that we change the coordinates of the center. This is where we would normally crank up our text editor and perform source code reuse. We make a copy of the implementation of points and change those parts where a circle is different from a point. struct Circle gets an additional com- ponent: int rad; This component is initialized in the constructor self —> rad = va_arg(* app, int); and used in Circle_draw():
